OPR-NH401H 4 Channels H.264 HDMI IP Streaming Encoder

OPR-NH401H 4 Channels H.264 HDMI IP Streaming Encoder - which supports input 4 HDMI at 1920x1080p@60fps, and output stream resolution at 1920x1080p@60fps. This Encoder works with SRT / HTTP / HLS / FLV / RTSP / RTMP(S) / UDP/RTP (Unicast/Multicast) Stream Protocols and ONVIF, etc.  Also the Encoder works with online live broadcast platform, such as YouTube, Facebook, Ustream, Twitter, etc.

Product features

1. Support 1-4 Channels HDMI input and encoding simultaneously.

2. Adopts professional encoding chip, embedded HiLinux System, high stability and efficiency.

3. Friendly Web Control UI, default IP is 192.168.1.168.

4. Support  SRT / HTTP / HLS / FLV / RTSP / RTMP(S) / UDP/RTP (Unicast/Multicast) Stream Protocols and ONVIF.

5. Support output Multi RTMP(S) (Main stream & Sub stream) to different Media Streaming Server.

6. Provide custom resolutions, Main Stream Preset Resolutions - 1920x1080, 1680x1200, 1600x900, 1440x1050, 1440x900, 1360x768, 1280x720, 1280x800, 1280x768, 1024x768, 1024x576, 960x540, 850x480, 800x600, 720x576, 720x540, 720x480, 720x404, 704x576, 640x480, 640x360, 480x270, etc.

7. Support Text and image insert as Stream Logo for Main stream & Sub stream.

9. Automatic detect the input video signals, output stream will show no signals when input signals interrupted.

10. Output Stream bitrate adjustable.

11. Support External Analog audio input.

12. Support Audio digital gain.

13. Support firmware upgrade.

Support remote control via router port forward.

Our Services
1. 1-Year Warranty.
2. Online, remote help.
3. Encoder Function customizes.
4. OEM & ODM welcomed.

Application
1. IPTV (Wowza, Xtream Codes Media Server, etc.)
2. Online Live Broadcast ( YouTube, Facebook, Ustream, Twitter, etc.)
3. NVR (Network Video Recorder)
4. Recording System / Software
5. Digital Signage
6. Teaching / Campus Broadcast
7. Hotel TV system
8. Video Conference
